BTM0102C2P

Feature:
Low power 3.3V operation
Easy to use command set for communications and control
Seamless connectivity with other Bluetooth devices
Fully embedded solution with no Bluetooth host stack required
Reference designs available at no additional cost
Low current consumption for long battery life
Firmware upgradeable

Realize agreement
* Realize Bluetooth serial profile.
* LM, LC, L2cap, SDP and RFCOMM


Class 2
with on-board antenna and PIN
BC02 CSR Chipset/ 3.3 V
SIZE: 30.02*12.4*2.7MM

Pin specification:
1. clearup saved Bluetooth address(input)
2. connect instruction output high level under connection(output)
3. clearup transmission(input)
4. request transmission(output)
5. serial data input
6. sleep/awaken(input),connect high level when it is free
7. do not connect
8. the source of power supply
9. the pressure of electrical source(input)

¡¡Documentation£º
¡¡¡¡¡¡Bluetooth embedded module manual.pdf
¡¡¡¡¡¡Bluetooth module manual.pdf
¡¡¡¡¡¡Bluetooth module AT Command Manual.pdf
